Going vertical: Bespoke facade solution in Czech Republic
09/01/2023 Stredočeský kraj, Czech Republic
Project details
- BUILT: January 2023
- LOCATION: Stredočeský kraj, Czech Republic
- BUILDING: Factory building of DOBIÁŠ spol. s r.o.
- USE OF ELECTRICITY: Self-consumption
- TYPE: Facade
- FACADE MATERIAL: Kingspan sandwich panels
- MODULE LAYOUT: landscape
- SYSTEM: SolidRail Light (two rail layers)
- NUMBER OF MODULES: 85
- CAPACITY: 32.3 kWp
- PARTNER: MP Technical Group s.r.o.
No standard? – No problem!
Our partner MP Technical Group s.r.o. really went the extra mile for this project in Stredočeský kraj, Czech Republic. The goal: Installing a self-consumption PV system on the factory building facade of DOBIÁŠ spol. s r.o., a construction element manufacturer.
“This particular project was quite challenging. We had to create a special load-bearing structure inside the hall, anchored to the support columns.”, says Martin Pokorny Jr., co-founder of MP Technical Group s.r.o.
SolidRail, a little different
After MP Technical Group s.r.o. had completed the dimensioning and installation of the support structure inside the building, our SolidRail was attached to it from the outside. It was installed in two rail layers, the first layer horizontally and the second vertically. In the end, the 85 black modules were clamped in landscape configuration on the long side. The black universal clamps OneMid and OneEnd definitely provided an aesthetical finish!
SolidRail is known from its numerous application areas on pitched roofs.
K2 goes vertical
There is a huge potential for facade PV systems. Projects like these have therefore inspired us to develop new standardized solutions: Our CarrierRail system for FischerTHERM Carrier® panels from Fischer Profil GmbH and other facade solutions are available since 2024.
Our partner
MP Technical Group s.r.o., headquartered in Chrastava, Czech Republic, is a comprehensive contractor of PV power plants for industrial and commercial buildings. The company, which has been active in the industrial sector for over 30 years, does not only realize projects in the Czech Republic, but also covers the Chinese, Italian and French markets.
